RPGMT Pixel Movement Plugin for RPG Maker MZ

RPGMT Pixel Movement replaces RPG Maker MZ's standard tile-by-tile movement with smooth sub-tile movement while keeping the familiar RPG Maker map, event and collision systems.

It combines precise player movement, 8-direction controls, event pixel movement, follower trails, custom hitboxes and powerful movement sequences in a single plugin.

The plugin is designed for developers who want smoother and more precise movement without replacing the entire RPG Maker workflow.

---

Key Features

• True sub-tile / pixel movement for the player
• Optional 8-direction movement
• Normalized diagonal movement speed
• Pixel movement for events
• Smooth pixel-based follower movement
• Follower trail system without visible snapping
• Adaptive follower catch-up
• Custom player hitboxes
• Custom event hitboxes
• Event-specific hitboxes through comments
• Pixel-aware Player Touch and Event Touch detection
• Precise movement distances such as 0.25, 0.5 or 1.75 tiles
• Relative X/Y movement
• Absolute map-position movement
• Player movement sequences
• Event movement sequences
• Random movement
• Approach Player movement
• Move Away From Player movement
• Wait and Turn sequence commands
• Custom JavaScript inside movement sequences
• Compatible with normal RPG Maker MZ movement routes

---

Pixel Movement

Characters are no longer limited to whole tile positions.

Instead of moving like this:

10 → 11 → 12

the player can move through fractional positions:

10.00
10.08
10.16
10.24
10.32
...
11.00

This allows much smoother and more natural movement while still using RPG Maker MZ's tile passability system.

---

8-Direction Movement

The player can move in all eight standard directions:

7 8 9
4   6
1 2 3

Diagonal speed can be normalized so diagonal movement is not faster than horizontal or vertical movement.

No special 8-direction character graphics are required. Standard RPG Maker MZ character sheets continue to work.

---

Custom Player Hitbox

The player collision area can be configured independently from the visual sprite.

Available settings include:

• Hitbox Width
• Hitbox Height
• Offset X
• Offset Y

This makes it possible to place the collision area around the character's feet instead of treating the full sprite as solid.

---

Custom Event Hitboxes

Events can use global default hitboxes or individual hitboxes through event comments.

Example:

<PixelHitbox: 0.70, 0.60>

With offsets:

<PixelHitbox: 0.70, 0.60, 0.00, 0.15>

The format is:

<PixelHitbox: width, height, offsetX, offsetY>

This is useful for NPCs, boxes, trees, narrow objects and other events where the default collision area is too large or too small.

---

Event Pixel Movement

Events can also use smooth sub-tile movement.

Normal RPG Maker movement commands remain usable, including:

• Move Up
• Move Down
• Move Left
• Move Right
• Diagonal movement
• Move Random
• Move Toward Player
• Move Away From Player
• Custom Move Routes

Pixel Movement can also be disabled for an individual event page:

<PixelMovement: off>

Or explicitly enabled:

<PixelMovement: on>

---

Smooth Followers

Followers use a recorded movement trail instead of repeatedly targeting whole tile positions.

This improves:

• Diagonal movement
• Sharp turns
• Curved paths
• Follower spacing
• Visual smoothness

Followers can also temporarily increase their movement speed when they fall behind and automatically return to normal speed once they catch up.

---

Precise Player Movement

The plugin includes several Plugin Commands for precise player movement.

Pixel Move Player

Move the player in one of eight directions by an exact distance.

Example:

Direction: Right
Distance: 0.25

This moves the player exactly 0.25 tiles to the right.

Pixel Move Player Offset

Move the player relative to the current position using exact X/Y offsets.

Example:

Offset X: 0.50
Offset Y: -0.25

This moves the player 0.5 tiles to the right and 0.25 tiles upward.

Pixel Move Player To Position

Move the player to an exact map coordinate.

Example:

X: 12.50
Y: 8.25

---

Player Movement Sequences

The Pixel Move Player Sequence command allows you to create complete movement sequences inside one Plugin Command.

Available sequence entries:

• Move Direction
• Random
• Offset X/Y
• Move To Position
• Wait
• Turn
• Custom Script

Example:

Move Right 0.50
Wait 20
Move Down 1.25
Turn Left
Wait 30
Move Left 0.25

Manual player input is disabled while a player sequence is active so the sequence cannot be interrupted by normal controls.

Sequences can also repeat continuously.

A separate Stop Player Sequence Plugin Command can stop repeating routes and return control to the player.

---

Event Movement Sequences

The Pixel Move Event Sequence command allows multiple event movement instructions to be created inside one Plugin Command.

Available movement types:

• Move Direction
• Random
• Approach Player
• Move Away From Player
• Offset X/Y
• Move To Position
• Wait
• Turn
• Custom Script

Example patrol route:

Move Right 1.50
Wait 30
Move Down 0.50
Move Left 1.50
Wait 30
Move Up 0.50

Enable Repeat Sequence to create a continuously repeating movement pattern.

You can also create simple autonomous behavior such as:

Random
Repeat Sequence: Yes

or:

Approach Player
Repeat Sequence: Yes

Please note that Approach Player uses direct movement and does not include pathfinding.

---

Custom Scripts

Movement sequences can run custom JavaScript.

Inside an Event Sequence, this refers to the event.

Example:

this.rpgmtMovePixel(6, 0.35);

Other examples:

this.moveRandom();
this.moveTowardPlayer();

Inside a Player Sequence, this refers to the player.

---

Move Route Script Calls

The following methods can also be used in normal RPG Maker MZ Movement Route Script commands.

Move by direction

this.rpgmtMovePixel(direction, distance);

Examples:

this.rpgmtMovePixel(6, 0.25);
this.rpgmtMovePixel(8, 1.50);
this.rpgmtMovePixel(3, 0.75);

Move by X/Y offset

this.rpgmtMovePixelXY(0.50, -0.25);

Move to exact map position

this.rpgmtMovePixelTo(12.50, 8.25);

The Movement Route waits until the precise movement has completed before processing the next route command.

---

Touch Events

Player Touch and Event Touch use the configured pixel hitboxes.

A configurable Touch Trigger Margin can slightly increase the contact area to make event activation feel more natural.

If a moving NPC enters the player's collision area, the player is still allowed to move out of the overlap. This prevents moving events from trapping the player.

---

Follower Settings

Follower behavior can be configured with:

• Follower Spacing
• Trail Sample Distance
• Trail Queue Limit
• Adaptive Catch-Up
• Catch-Up Start Distance
• Full Catch-Up Distance
• Maximum Catch-Up Multiplier

---

Compatibility API

The plugin creates:

window.RPGMT.PixelMovement

Example:

if (window.RPGMT?.PixelMovement?.isAvailable()) {
    // RPGMT Pixel Movement is installed
}

Available helper examples include:

window.RPGMT.PixelMovement.playerPosition();
window.RPGMT.PixelMovement.playerHitbox();

window.RPGMT.PixelMovement.startPlayerSequence(steps, options);
window.RPGMT.PixelMovement.cancelPlayerSequence();

window.RPGMT.PixelMovement.startEventSequence(eventId, steps, options);
window.RPGMT.PixelMovement.cancelEventSequence(eventId);

This API can be used by future RPGMT movement extensions or other compatible plugins.

---

Important Notes

• Designed for RPG Maker MZ.
• Uses rectangular hitboxes, not sprite alpha-pixel collision.
• Uses RPG Maker MZ's normal tile passability as the map collision basis.
• Pathfinding is not included.
• Approach Player can still be blocked by walls.
• Event comment settings apply to the current event page.
• Event ID 0 refers to the event currently executing the Plugin Command.

---

Version 1.2.3

• Pixel Movement for player and events
• 8-direction movement
• Pixel follower trail system
• Player and event movement sequences
• Precise hitboxes and offsets
• Fractional movement distances
• Custom movement scripts
• Player overlap escape handling

---
